Hexadecimal color code for transparency in Android

Kirti K
3 min readJun 1, 2021

--

Hexadecimal

Transparency is controlled by the alpha channel (AA in #AARRGGBB). Maximal value (255 dec, FF hex) means fully opaque. The minimum value (0 dec, 00 hex) means fully transparent. Values in between are semi-transparent, i.e. the color is mixed with the background color.

To get a fully transparent color set the alpha to zero. RR, GG and BB are irrelevant in this case because no color will be visible. This means #00FFFFFF ("transparent White") is the same color as #00F0F8FF ("transparent AliceBlue"). To keep it simple one chooses black (#00000000) or white (#00FFFFFF) if the color does not matter.

- you’ll find Transparent defined as #00FFFFFF.

Example: For 85% white, you would use #D9FFFFFF. Here 85% = "D9" & White = "FFFFFF"

All hex value from 100% to 0% alpha:

  • 100% — FF
  • 99% — FC
  • 98% — FA
  • 97% — F7
  • 96% — F5
  • 95% — F2
  • 94% — F0
  • 93% — ED
  • 92% — EB
  • 91% — E8
  • 90% — E6
  • 89% — E3
  • 88% — E0
  • 87% — DE
  • 86% — DB
  • 85% — D9
  • 84% — D6
  • 83% — D4
  • 82% — D1
  • 81% — CF
  • 80% — CC
  • 79% — C9
  • 78% — C7
  • 77% — C4
  • 76% — C2
  • 75% — BF
  • 74% — BD
  • 73% — BA
  • 72% — B8
  • 71% — B5
  • 70% — B3
  • 69% — B0
  • 68% — AD
  • 67% — AB
  • 66% — A8
  • 65% — A6
  • 64% — A3
  • 63% — A1
  • 62% — 9E
  • 61% — 9C
  • 60% — 99
  • 59% — 96
  • 58% — 94
  • 57% — 91
  • 56% — 8F
  • 55% — 8C
  • 54% — 8A
  • 53% — 87
  • 52% — 85
  • 51% — 82
  • 50% — 80
  • 49% — 7D
  • 48% — 7A
  • 47% — 78
  • 46% — 75
  • 45% — 73
  • 44% — 70
  • 43% — 6E
  • 42% — 6B
  • 41% — 69
  • 40% — 66
  • 39% — 63
  • 38% — 61
  • 37% — 5E
  • 36% — 5C
  • 35% — 59
  • 34% — 57
  • 33% — 54
  • 32% — 52
  • 31% — 4F
  • 30% — 4D
  • 29% — 4A
  • 28% — 47
  • 27% — 45
  • 26% — 42
  • 25% — 40
  • 24% — 3D
  • 23% — 3B
  • 22% — 38
  • 21% — 36
  • 20% — 33
  • 19% — 30
  • 18% — 2E
  • 17% — 2B
  • 16% — 29
  • 15% — 26
  • 14% — 24
  • 13% — 21
  • 12% — 1F
  • 11% — 1C
  • 10% — 1A
  • 9% — 17
  • 8% — 14
  • 7% — 12
  • 6% — 0F
  • 5% — 0D
  • 4% — 0A
  • 3% — 08
  • 2% — 05
  • 1% — 03
  • 0% — 00

How is it calculated?

FF is a number written in hex mode. That number represents 255 in decimal. For example, if you want 42% to calculate you need to find 42% of number 255 and convert that number to hex. 255 * 0.42 ~= 107 107 to hex is “6B”

BE AWARE 👇🏼

In HTML/CSS (browser code) the format is #RRGGBBAA with the alpha channel as the last two hexadecimal digits.

--

--
